| 說明 | Description |
Unit
|
ARES 450-S+
|
||
| 射膠系統 | Injection Unit | ||||
| 螺桿直徑 | Screw diameter |
mm
|
70
|
80
|
90
|
| 螺桿長徑比 | Screw L/D ratio |
—
|
24
|
21
|
18.7
|
| 理論射膠容積 | Theoretical shot volume |
cm3
|
1501
|
1960
|
2481
|
| 射膠量(PS) | Shot weight (PS) |
g
|
1381
|
1804
|
2283
|
| 射膠壓力 | lnjection pressure |
MPa
|
212
|
162
|
128
|
| 注射速率 | Injection rate |
g/s
|
383
|
497
|
636
|
| 螺桿行程 | Screw stroke |
mm
|
390
|
||
| 螺桿轉速 | Screw speed |
rpm
|
155
|
||
| 鎖模系統 | Clamping Unit | ||||
| 鎖模力 | Clamping force |
kN
|
4500
|
||
| 推力座行程 | Opening stroke |
mm
|
780
|
||
| 導柱內距(水平×垂直) | Space between tie bars (HxV) |
mm
|
830 x 780
|
||
| 模板最大距離 | Max. daylight |
mm
|
1590
|
||
| 最薄-最厚 | Mold thickness (Min-Max) |
mm
|
330 – 820
|
||
| 頂針行程 | Ejector stroke |
mm
|
200
|
||
| 頂針推力 | Ejector force |
kN
|
150
|
||
| 頂針桿根數 | Ejector number |
pcs
|
17
|
||
| 動力/電熱 | Power/heating unit | ||||
| 系統壓力 | System pressure |
MPa
|
16
|
||
| 伺服電機功率 | Motor pump capacity |
kW
|
62
|
||
| 電熱功率 | Heating capacity |
kW
|
32
|
||
| 溫度控制區數 | Number of temperature control zones |
—
|
5 + Nozzle
|
||
| 其它 | Others | ||||
| 料斗容積 | Hopper capacity |
L
|
100
|
||
| 油箱容量 | Oil tank capacity |
L
|
700
|
||
| 機身尺寸(長×寬×高) | Machine dimensions (L×W×H) |
m
|
8.8 x 2.0 x 2.6
|
||
| 機重 | Machine weight |
T
|
20
|
||
